THE rayvolt cruzer.

Yesterday's charm. Tomorrow's technology.



Good things come in 3's

The Rayvolt Cruzer is available in British Green, Clockwork Orange and Gun Metal Grey.

British Green

Clockwork Orange

Gun Metal Grey


The ingenuity is in the detail


Interested? Start now.




Features



The Motor - best possible torque

Rayvolt hubs consist of an advanced brushless 3 phase DC motor with 48 different copper coils and magnets. These are placed on the outermost perimeter of the motor for the best possible torque. It's also incredibly safe. The built-in controller receives both heat and position data from the coils computing where to put the next load within one millisecond.

Such accuracy produces a Pure Sine Wave (PSW) current, offering unmatched ride comfort:

  • More Acceleration
  • More Response
  • More Torque
  • Less Noise
  • Less Vibration
  • Less Consumption

Batteries - Fast, safe and secure

Your Cruzer's performance is directly linked to the cell, which forms the core of the E-Bike. To provide optimum performance, the Cruzer uses 13 cells in a series to reach a nominal voltage of 48V. At peak voltage, a full charge of 54.6V gives incredible power. Depending on your Cruzer model, a minimum of 4 cells are used in parallel - 52 cells in total - or 8 cells in parallel - 104 Cells in total. This gives an unmatched capacity of 550Wh and 1100Wh respectively.

The quality does not end there. Using a state-of-the-art battery management system in our packs, we connect each cell to it before delivering the charge. This high-tech design balances the charge between each individual cell and can cut the connection in case of a short circuit. Ultimately, this ensures best possible performance while making the battery safer.



Brakes - An "ultra-powerful dynamo"

The Cruzer is all about performance and efficiency, which is why we designed an electronic braking system that converts torque into resistance that recharges the battery. This is achieved by sending data signals to the motor controller and provoking a reverse effect in the motor, using wheel inertia to generate electricity.

In simple words, the regenerative braking acts like an ultra powerful dynamo when the levers are pulled.

The intelligent iRBS is linked to EIVA's built-in gyroscope allowing the bike to detect the cycling environment. It then provides the necessary amount of regenerative brake according to the angle of the hill.


Intelligent Pedal Assist (IPAS)

The Cruzer's iPAS provides power when you need it through the assistance of gyroscope hill detection, self-adjusting the motor to your environment. The electronic crank also comes fitted with a load cell, measuring both the torque applied to the pedal and the crank rotary speed. A controller computes these values, using a smart algorithm to provide perfectly smooth power based on muscle activity.



EIVA

The EIVA®, short for Electronic Intelligent Vehicle Assistant, is a Rayvolt's developed software to control, customize and monitor your Rayvolt bike. An EIVA® computer can be purchased and securely mounted to your Cruzer's handlebars, ready to go whenever you are. Prefer to use your own device? No problem. The software can also be downloaded for use on your personal Android or iPhone.

Eiva comes with:

Display 360º
Monitor speed, battery state, MPH/KM run and essential bike specs.

Bluetooth bike status
Monitor the connection between the bike and EIVA®.

iPAS Monitoring
Adjust your pedal assistance to meet your needs.

Settings
Advanced configurations and technical support chat.

Music
Play music to enhance your Cruzer experience.

Maps
GPS access pinpoints your location and lets you know how far you've travelled - and still need to travel.

Information
Troubleshooting for when you need it.


Own the most elegant E-Bike on the road.


Original Parts and Accessories

Make sure your Cruzer fits your lifestyle.


TECHNICAL SPECIFICATIONS

Ensuring you have both style and quality, from start to finish.

Bike


Battery Cover

  • Composite shell covered by leather

Chain

  • KMC Extralong silver chain

Brakes

  • Rayvolt Oil Disk Brakes
  • with E-Regenerative 10A-50A

Crankset

  • Rayvolt Two pieces Crankset

Pedals

  • Flat Rayvolt pedals

Spokes

  • 13G for the back HUB
  • Regular 26" for the front tire

Rims

  • Double wall 40 mm wide

Saddle

  • Vintage spring genuine leather

Speed control

  • PAS (Pedal Assistant System Thumb Throttle)

Frame weight

  • 34 kg

Wheels & Tyres

  • 26" x 3"

Light kit

  • Headlight LED
  • Red Backlight LED

E-Drive system

  • Rayvolt EIVA®

Motor


Rayvolt SMART HUB

  • 200W - 400W (25km/h)

Rayvolt POWER HUB

  • 250W - 1000W. (43 km/h)

Battery


Life of 1000 cycles

SAMSUNG Li-ion Dual

  • 48V-21A

SAMSUNG Li-ion

  • 48V-10,5A

Charger


Li-Ion Smart Charger

  • 54V and 4 A. 2h30m charge time
